2 kW Solar Grid-Tie Systems


RGJ International SAs Grid-tie Solar Kits provide a way for you to produce the energy you consume, reduce your electric bill and protect the planet.


Reduce Your Electric Bill

Producing your own power offsets the electricity you purchase from your utility. Because a RGJ International SA Grid tie Solar Kit is a one-time investment, the price of the electricity you generate from solar doesn't increase and protects you from increasing electricity costs.

State and Federal Incentives

Many states and municipalities offer significant incentives to encourage installing a solar system. Federal tax incentives are also available. All systems we carry follow the strict guidelines set by government agencies for incentive eligibility and we provide all of the necessary documentation for inspection.

Our 2 KW Grid-Tie Systems are ideal for residential or light-commercial systems.

SHARP 2.16 kW Solar System
• 10 Sharp ND-216 (216W) Solar Modules
• Sunny Boy SMA 3000US Grid-tie Inverter
• Rail, Clamp & Splice Mounting System (Portrait Format)
• AC Disconnect, MC Cables, Ground Lugs & Wiring Diagram
Solar Array Area:
179 Sq. Ft.

Solar Module Size:
64.6" x 39.1" x 1.8"
$12,795


SUNTECH 2.10 kW Solar System
• 10 Suntech STP210-18/Ub-1 (210W) Solar Modules
• Sunny Boy SMA 3000US Grid-tie Inverter
• Rail, Clamp & Splice Mounting System (Portrait Format)
• AC Disconnect, MC Cables, Ground Lugs & Wiring Diagram
Solar Array Area:
161 Sq. Ft.

Solar Module Size:
58.3" x 39.1" x 1.4"
$12,654

What's included in our complete
solar grid tie systems?
• Photovoltaic solar modules
• Grid tie inverter
• Mounting rails and clamps
• Solar MC cables
• Grounding lugs
• Array Combiners in larger systems
• AC and DC solar disconnect
• Site specific electrical single and three line schematics
• AC and DC wire sizing/type will be specified in
our electrical schematics
• CA stamped structural testing reports for the
mounting system
• Component installation manuals
• Technical assistance
Product Spec Sheets
Sharp ND-216UC1
Suntech STP210-18
Sunny Boy SMA 3000US

Contact Us :

sales(@)rgjinternationalsa.com
Telephone : +33665735074
Use our contact page Here


Mounting System
Our standard residential grid-tie systems include all support rails & module clamps.
This mounting system has been load-tested and engineered to 125mph wind load (50 lbs/square foot of pressure load) for most module types. Our mounting system secures the solar panels and prevents damage caused from high-winds and seismic forces. The support rail was designed to conceal all attachment hardware. All connections are made inside the support rail hidden from view. All exposed aluminum is fully anodized to module manufacturer specifications.

AC Disconnect Switch
Many utilities require an AC disconnect between a grid-tie inverter and the AC load center, close to the AC service entrance, with a visible and lockable handle.
UL Listed to handle 12A a 600 VDC per pole, also can be used for disconnecting up to three PV arrays for three grid-tie inverters.
For connection of multiple inverters to one of these disconnects, use an AC load center, with a circuit breaker for each inverter installed, as an AC combiner box between the inverters and the disconnect switch. The breakers can be back-fed with the inverter outputs and the load center main lugs will handle the combined outputs to be connected to the AC disconnect.

Sunny Boy SMA 3000US
The newest Sunny Boy 3000 grid-tie inverter has been updated with SMA's most advanced technology and is designed specifically to meet the new IEEE 1547 requirements. The compact design makes it ideal for light commercial or residential use.
Increased efficiency of up to 96.6% means better overall performance and shorter payback periods. All SMA inverters are engineered and built to last. The SMA3000US now comes with a standard ten-year warranty. Sunny Boy inverters are trusted worldwide to go the distance year-round.
Sunny Boy inverters are housed in a watertight stainless steel NEMA 3R outdoor enclosure. The SMA US Series can operate in extreme conditions (ambient temperatures of -13F to +113F). They can be mounted right behind the solar module array on the roof, on a wall, or on the ground.

MC Solar Cables
The MC Solar connectors deliver a flexible system solution for time-saving, dependable series-cabling of solar modules. Most module manufacturers supply their grid-tie modules with pre-assembled output cables, tested and ready for connection. This saves considerable time during an installation and greatly increases reliability over wire junction boxes. These cable couplers are fully touch protected and designed for up to 1000 volts and 30 amps. They are also waterproof. For parallel connection of modules in 12 to 48 volt systems, MC Solar cables makes branch connectors for use with currents up to 30 amps.
